Fully Aurtomatic Insulating Oil Testr, Bdv Testing Instrumemts

Application:
The ST Oil Dielectric AC Test Sets provide repeatable, accurate measurement of breakdown voltage of insulating oils used in electrical equipment. These versatile, lightweight yet rugged units have been designed for both field and laboratory use.

The ST Oil Dielectric AC Test Sets adopt industrial SCM to control, which is applied to integrate circuit, new model I/0 connection, particular testing and anti-jamming technology which largely improve the machine's capacity .

Features:
?Zero Start" and test chamber interlock provision
? Window panel for test observation
? 80 KV & 100 KV test cells for ASTM & IEC standards
?Simple operation, automatically (can be finished just press on key)
?Menu controlled. Input data can clear
?Can store 99 groups oil testing data which is convenient to reading and print. ?The testing data can keep 100 years under the condition of power off.
?System time can go on running under power off;
(The system time just for reference cannot be the standard of timing)


Technology and parameter data:
1.Power supply: AC220V ±10%, 50 HZ (Customizable)
2. Voltage output: 80KV, 100KV
3. Capacity: 1.6KVA, 2.0KVA
4. Pressure increase rate: About 2 KVA/S
5. Pressure testing speed: 3%
6. Break down sensitivity : <2KV
7.Wave form distortion :≤3%
8.Time of break down: ≤10ms
9.Operational environment: Temperature:0ºC-40ºC, Humidity: the most relative humidity85%
10.Storage environment : Temperature:-20ºC-60ºC, Humidity: the most relative humidity75%.


Please contact us for more details.
