Soil Plate Bearing Load Test Apparatus 500kn
Soil Plate Bearing Load Test Apparatus 500knThese test methods are used to estimate the bearing Capacity of a soil under field loading conditions for a Specific loading plate and depth of embedment (ASTM D1194) but also for load tests of soil and flexible pavement Components for use in evaluation an......
Send Inquiry
Product Description
Soil Plate Bearing Load Test Apparatus 500kn
These test methods are used to estimate the bearing Capacity of a soil under field loading conditions for a Specific loading plate and depth of embedment (ASTM D1194) but also for load tests of soil and flexible pavement Components for use in evaluation and design of airport and Highway pavements (ASTM D1195, D1196; BS 1377; CNR No. 92 and No. 146; DIN18134). We propose a complete Range of plate load testing equipment conforming to the Different standards.
CTK-3 model:
CTK-500 model:
These test methods are used to estimate the bearing Capacity of a soil under field loading conditions for a Specific loading plate and depth of embedment (ASTM D1194) but also for load tests of soil and flexible pavement Components for use in evaluation and design of airport and Highway pavements (ASTM D1195, D1196; BS 1377; CNR No. 92 and No. 146; DIN18134). We propose a complete Range of plate load testing equipment conforming to the Different standards.
CTK-3 model:
| Load plate diameter: | 300 mm |
| Jack load capacity range: | 0-300 kN |
| Jack Stroke: | 120 mm |
| Measuring bridge span: | 3000 mm |
| Hand pump rated pressure: | 70 Mpa |
| Stress test range: | 0-25 Mpa |
| Displacement measurement range: | 0-10 mm |
CTK-500 model:
| Load plate diameter | 30cm 45 cm 60cm 75 cm |
| Jack load capacity range | 0-500 kN |
