Product Description
Ultraviolet Aging Test Chamber
Product overview
The uv aging chamber simulates the effect of sunlight exposure by fluorescent ultraviolet lamp. The tested material is placed in the light at a certain temperature for testing.The weathering effects of months or years outdoors can be reproduced in days or weeks.
Related introduction
1.UV aging test box contains UV irradiation and temperature control functions. Users can set the test time by themselves. The total test time is equipped with power outage maintenance function.The machine adopts 15W ultraviolet lamp tube as the light source, through simulating the ultraviolet radiation condition in the natural sunlight, carries on the accelerated weather resistance test to the material, obtains the weather resistance result of the material.The effective service life of the lamp tube can be about 1500 hours.
2, the company's unique structure design, beautiful and generous, more convenient for users to operate.
3, the box is made of stainless steel, durable.
Conditions of use
The machine should be placed in an indoor environment with <=35ºC and ≤ 85%R.H;Please install AC220V/5A or above power supply, in order to ensure the safety of operators, confirm the ground wire safety grounding.
Main technical parameters
Technical indicators
Studio size: W 400×D280×H250 (mm)
Use light source: 15W UV-B UV two
Wavelength peak: 313nm
Center distance between tubes: 150mm
Temperature range: Up to 60ºC
Sample rack: adjustable (i.e. adjustable distance between lamp tube and sample)
Timing device: Maximum timing 9999H;With power off function, continue to work after the call.
Recommended operating environment: <=35ºC, 40% ~ 85%R.H.
Product overview
The uv aging chamber simulates the effect of sunlight exposure by fluorescent ultraviolet lamp. The tested material is placed in the light at a certain temperature for testing.The weathering effects of months or years outdoors can be reproduced in days or weeks.
Related introduction
1.UV aging test box contains UV irradiation and temperature control functions. Users can set the test time by themselves. The total test time is equipped with power outage maintenance function.The machine adopts 15W ultraviolet lamp tube as the light source, through simulating the ultraviolet radiation condition in the natural sunlight, carries on the accelerated weather resistance test to the material, obtains the weather resistance result of the material.The effective service life of the lamp tube can be about 1500 hours.
2, the company's unique structure design, beautiful and generous, more convenient for users to operate.
3, the box is made of stainless steel, durable.
Conditions of use
The machine should be placed in an indoor environment with <=35ºC and ≤ 85%R.H;Please install AC220V/5A or above power supply, in order to ensure the safety of operators, confirm the ground wire safety grounding.
Main technical parameters
Technical indicators
Studio size: W 400×D280×H250 (mm)
Use light source: 15W UV-B UV two
Wavelength peak: 313nm
Center distance between tubes: 150mm
Temperature range: Up to 60ºC
Sample rack: adjustable (i.e. adjustable distance between lamp tube and sample)
Timing device: Maximum timing 9999H;With power off function, continue to work after the call.
Recommended operating environment: <=35ºC, 40% ~ 85%R.H.
